ELECTRIC HYDRAULIC TRIM & TILT UP TO 130HP
R30,995
CMC, PT-130 Tilt & Trim, up to 130 HP, with gauge. With the Electric Hydraulic Tilt & Trim you get power tilt & trim, better boat handling, more speed, lower fuel consumption and no more back strain. *S*
- Description
- in the box
- Shipping
Description
– Rated for 130HP and smaller motors
– 6″ Set back to enhance boat stability and performance
– 20° of Trim and a total of 90° of tilt & trim
– 1/2″ 6061 T6 extruded aluminium construction with stainless steel fasteners
– Electric hydraulic actuator rated at 7853 lbs. of thrust!
– Standard B.I.A. bolt hole pattern
– Convenient adapter kit available for clamp-on motors
– Four stainless steel motor mounting bolts included
Hydraulic PT-130 Unit x 1
Wire Assembly x 1
Trim Gauge and Wire Assembly x 1
1/2” – 13 x 3 Stainless Steel Hex Head Cap Screws x 4
1/2” – 13 Stainless Steel Hex Nuts x 4
1/2” Stainless Steel Lock Washers x 4
1/2” Stainless Steel Flat Washers x 4
Up-down Toggle Switch x 1
Additional information
| Weight | 21 kg |
|---|---|
| Dimensions | 50 × 39 × 17 cm |
